China High Performance GUTE Reinforce Bar Straightening-Cutting Machine GT4-14CG
Product Description
Steel Bar Straightening-Cutting Machine
| CUTTING CAPACITY | 4-14 mm (ob ≤450N/mm2) | ||
| TRACTION MOTOR | YB2M4-4 | ||
| MOTOR POWER | 4,0 KW -4P | ||
| STRAIGHTENING MOTOR | YB2M4-4 | ||
| MOTOR POWER | 11 KW-4P | ||
| CUTTING MOTOR | YDX 132S4-4 | ||
| MOTOR POWER | 4,0 KW-4P | ||
| PULLING SPEED | 50-65m/min | ||
| NOISE VALUE (1m away) | ≤80dB(A) | ||
| WEIGHT | 1.372 Kg. + 25 Kg. | ||
| DIMENSIONS (L*W*H) | 3150*800*1200 mm | ||
| UNIT PRICE USD | |||
| CERTIFICATION | ISO 9001:2008 |
PRODUCT DESCRIPTION
• GT4-14CG has adjustable speed and traction motor to ensure reliable bar pulling-in and to avoid scratches or rigidity loss.
• DIGITAL CONTROL by the control cabinet that features the ENCODER for the straightening and cutting adjusting, it can memorize multiple setting of different length and number of pieces.
• STRAIGHTENING WHEELS, PULLING WHEELS, SQUARE BLADE, ROUND BLADE made of high-quality alloyed steel with proper heat treatment (quenching) and 2mm thick external case to ensure high performances also under heavy loads and long working life.
• Meter counter on the external straightening wheels for stirrup length accuracy. • ISO 9001:2008 certification.
---CONSTRUCTION SITE
----CERTIFICATION
----WORLWIDE PARTNER
---OUR SHOP
Product Categories : Small -Sized Machinery > Digital Steel Bar Straight-Cutter
